Prekės informacija

Bendrosios charakteristikos

Prekės tipas
UPS įtampos stabilizatoriai

Prekės ženklas
Ever
Modelis
T/ELCDTO-001K00/00
Gylis
31.5 cm
Plotis
8 cm
Aukštis
27 cm
Spalva
Juoda
Galia
600 W
Galia (VA)
1000
Akumuliatoriaus talpa
9 Ah
Darbinė temperatūra
0 - 40 °C
Ekranas
Taip
Išėjimai
8 x IEC 320 C13
Garantija
24 mėn

Prekės atspalvis gali skirtis nuo matomo nuotraukoje.

Prekės aprašymas anglų kalba:

Application :	Home and small office
UPS family :	ECO LCD
Apparent output power [VA]:	1000
Active output power [W]:	600
Topology :	VFD (offline)
Number of phases (Input / Output) :	1 / 1
Housing Type :	Tower
Operating temperature [°C]:	0 ÷ +40
Cooling :	Gravity
Nominal input voltage [V]:	~ 230
Input voltage range (effective values) [V] and tolerance [%]:	~ 190 ÷ 259 ± 5
Input voltage rated frequency [Hz]:	50
Input voltage frequency range [Hz] and tolerance [Hz]:	45 ÷ 55 ± 1
Transfer thresholds: mains - UPS [V]:	~ 190 ÷ 259 ± 5 %
Nominal output voltage [V]:	~ 230
Output voltage range (effective) [V] and tolerance [%] - mains operation :	~ 190 ÷ 259 ± 5
Output voltage range [V] and tolerance [%] - battery mode :	~ 230 ± 10
Shape of output voltage (battery mode / normal mode) :	Stepped approximation of sine wave / Same as input
Output voltage rated frequency [Hz]:	50
Output frequency range and tolerance - mains operation mode [Hz]:	Synchronously
Output frequency range and tolerance - battery mode [Hz]:	50 ± 1
Output voltage filtering :	LC
Transfer thresholds: UPS – Mains [V]:	~ 200 ÷ 249 ± 5 %
Transfer time to battery mode [ms]:	< 6
Transfer time to normal mode [ms]:	0
Internal batteries :	12 V / 9 Ah VRLA
Number of internal batteries :	2
Maximum overall internal batteries capacity [Ah]:	9
Back-up time - internal batteries (100% / 80% / 50% Pmax) [min]:	4 / 6 / 14
Nominal voltage DC circuit [V]:	24
Internal batteries maximum charging time - after discharging at 80 % Pmax [h]:	10
Dimensions (H x W x D) [mm]:	270 x 80 x 315
Net weight [kg]:	7,1
Gross Weight (with batteries) [kg]:	8,1
Transport Dimensions (H x W x D) [mm]:	355 x 150 x 398
Position in which devices transported :	Vertical
Maximum length of output cables [m]:	< 10
Input over current protection :	Short-circuit protection – Circuit breaker 8 A / 250 V AC; Surge Protection
Output over current protection :	Electronic short-circuit and overload protection
Power supply connection :	Power cord ended with plug with ground terminal 16A (PN-E-93201:1997) + uni-schuko
Output connections (numbers & type of outlets) :	4 x IEC 320 C13 (10 A) battery and surge protected 4 x IEC 320 C13 (10 A) surge protected
Signaling :	Acoustic and optical; LCD display
Communication interfaces :	USB
LAN filter - RJ45 :	LAN 10/100 Base-T
Monitoring & management software :	PowerSoft Professional
Cold start :	YES
