Prekės informacija

Bendrosios charakteristikos

Prekės tipas

UPS akumuliatoriai

Prekės ženklas

CSB

Ilgis

151 mm

Plotis

65 mm

Aukštis

94 mm

Matmenys

151 x 94 x 65 mm

Svoris

3.67 kg

Baterijos talpa

0.012 Ah

Garantija

24 mėn

Prekės atspalvis gali skirtis nuo matomo nuotraukoje.

GP12120 12V 12AhGP 12120 is a general purpose battery up to 5 years in standby service or more than 260 cycles at 100% discharge in cycle service.As with all CSB batteries, all are rechargeable, highly efficient, leak proof and maintenance free. Specification Cells Per Unit 6 Voltage Per Unit 12 V Capacity 12 Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F) Weight (kg) Approx. 3.67kg. (8.09 lbs.) Maximum Discharge current (A) 150/180A (5sec.) Internal Resistance Approx. Approx. 16.7 mΩ Operating Temperature Range Discharge：-15℃~50℃(5°F~122°F)Charge：-15℃~40℃(5°F~104°F)Storage：-15℃~40℃(5°F~104°F) Nominal Operating Temperature Range 25°C ± 3°C (77°F ± 5°F) Float charging voltage 13.5 to 13.8 VDC/unit Average at 25°C (77°F) Recommended Maximum Charging current limit 3.6 A Equalization and Cycle Service 14.4 to 15.0 VDC/unit Average at 25°C (77°F) Self Discharge It should be more than 75% of the capacity that before storage after stocked for 6 months at ambient temp. 25℃ Terminal F1/F2-Faston Tab187/250 Container Material ABS(UL94-HB) & Flammability resistance of(UL94-V0) can be available upon request.
