Prekės informacija

Bendrosios charakteristikos

Prekės tipas
Monitoriai

Prekės ženklas
LG
Monitoriaus tipas
Pramoniniai monitoriai
Modelis
55UH7F-H
Spalva
Juoda
Energinio efektyvumo klasė
G
Energijos efektyvumo klasės skalė
A - G

Ekranas

Ekrano tipas
IPS

Ekrano įstrižainė
55 "
Ekrano raiškos tipas
4K UHD
Ekrano raiška
3840 x 2160
Ekrano forma
Plokščias
Ekrano paviršiaus tipas
Matinis
Reakcijos laikas
8 ms
Horizontalus stebėjimo kampas
178 °
Vertikalus stebėjimo kampas
178 °
Kontrastas
1100 : 1
Ryškumas, cd/m²
700
Liečiamas ekranas
Ne
3D funkcija
Ne

Jungtys ir sujungimai

USB 2.0 jungčių skaičius
1

Jungtys
Audio In, Audio Out, DisplayPort, HDMI, RJ-45, RS232C
HDMI lizdų skaičius
2
Galima nuotolinio valdymo funkcija
Ne

Integruoti papildomi įrenginiai

TV funkcija
Ne

Įmontuotos garso kolonėlės
Taip

Matmenys ir svoris

Plotis
123.4 cm

Aukštis
72 cm
Gylis
3.99 cm
Svoris
19 kg

Papildomai

Reguliuojama
Ne

Tinka montavimui prie sienos
Taip
VESA standartas
300 x 300
nVidia G-Sync
Ne
AMD FreeSync
Ne
Komplekte
Monitorius; HDMI kabelis, maitinimo kabelis, kiti priedai
Garantija
24 mėn

Prekės atspalvis gali skirtis nuo matomo nuotraukoje.

SUPERB PICTURE QUALITY
Clear View with Non-glare Coating
Viewers can be annoyed by unnecessary reflections when watching a screen under brightly lit conditions. The UH7F-H series has resolved such inconveniences by increasing the level of haze, which enhances visibility and text readability.
*The images listed are for reference only and the actual reflection can be different.
With a resolution 4 times higher than FHD, ULTRA HD displays content more clear and realistic.

SUPERB PICTURE QUALITY
ULTRA HD Resolution
With the resolution that is 4 times higher than FHD, it makes the color and details of the contents more vivid and realistic. In addition, the wide viewing angle applied with an IPS panel, provides clear contents.
UH7F-H has a narrow bezel of 14.4mm width and 9.9mm length, and a slim depth of 39.9mm which increases screen immersion.

SLEEK AND PRACTICAL DESIGN
Narrow Bezel & Slim Depth
This series is thin in bezel size and thickness, which saves space and enables easy installation. In addition, it increases the immersive experience from the screen and provides a sophisticated design, improving the décor of the space where the product is installed.
Logo is detachable when installing signage, and the built-in speaker is making the sound rich.

Detachable Logo and Built-in Speaker
This series is equipped with a new transparent logo which is well organized with surroundings. Also, its removable feature gives users flexibility for installation. Contents will be enriched with sound effects from built-in speakers, without the need for purchasing or installing external speakers.
UH7F-H is IP5x certified, so it is protected from dust and has less risk of performance degradation.

IP5x Certified Design
The IP5x Dust-Proof Certification ensures that the product is protected from dust, reducing the risk of performance degradation.
UH7F-H can be installed flexibly up to a 30 degree angle, making it comfortable for users to see when a signage is installed at a high place.

30° Tilting Installation
For the user's comfort viewing, UH7F-H supports the installation with 30 degrees of tilt* when it is installed at high places.
*Tilt installation of up to 30 degrees facedown is supported. (In conditions within 30ºC temperature, 50% humidity)
The UH7F-H series automatically adjusts the orientation of the screen, so users do not have to change the setting themselves.

EASY INSTALLATION
Auto Screen Rotation
This series automatically detects its orientation (landscape or portrait mode) in the initial installation step, so manual rotation set-up process isn't required. The direction of OSD and background contents will be already set when you turn on a display at first.

EASY INSTALLATION
Fine Adjustment
This series is equipped with a "horizontal sensor" which shows users how the device is tilt, so that it can be precisely installed.

High-Performance with webOS
Built-in Quad Core SoC can execute several tasks at once while providing smooth content playback. Also, LG webOS platform enhances user convenience with intuitive GUI and simple app development tools.
The image shows that various external sensors and signage can be connected through USB plug-in, providing easy value-added solutions.

Various Sensor Connection
LG webOS smart signage platform helps to easily provide value-added solutions by supporting simple connections with external sensors* such as GPIO, NFC/RFID, temperature sensors, etc. via USB plug-in. Also, the cost for additional software or media players can be saved by reducing the needs for purchasing them.
*LG does not provide any external sensors but webOS platform. External sensors needs to be purchased separately and tested for compatibility with webOS platform.

Compatible with AV Control System
The UH7F-H series has supported Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control*, boosting business management efficiency.
*Network based control

Compatible with Video Conference System
For the optimum visual meeting, the UH7F-H series has supported its compatibility with Cisco System that offers powerful and integrated control* for a smarter video conference, eliminating a waste of time for setting up the picture quality or changing input on incoming calls.
