Prekės informacija

Bendrosios charakteristikos

Prekės tipas
Komutatoriai (Switch)

Prekės ženklas
Extra Digital
Modelis
POE2404L
Gylis
440 mm
Plotis
284 mm
Aukštis
44 mm
Svoris
4200 g
Spalva
Juoda
Korpuso medžiaga
Metalas
Tinklo standartai
IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE802.3u
Tinklo (LAN) jungčių greitis
10/100/1000 Mbps
Base T jungčių skaičius
24
Įtampa
110 - 240 V
Garantija
24 mėn

Prekės atspalvis gali skirtis nuo matomo nuotraukoje.

Features:

POE switches Hisource is designed to meet the demand of POE power supply part and design of research and development of independent innovation of gigabit POE switches, using the latest high-speed Ethernet switching chip, high back bandwidth design, with high speed data processing ability, improve the smooth data transmission.There are 24 MB RJ45 ports, 2 gigabit RJ45 ports and 2 SFP fiber module slots.All of the 24 megabit RJ45 ports support IEEE 802.3af/at standard PoE, with the maximum power supply of 30W, the maximum of 400W.Automatic detection and identification of electrical devices that meet the IEEE 802.3af/at standard and power supply through the network line.

Provide 24 10/100m adaptive high-speed forwarding data without losing packet RJ45 port.

Provide 2 10/100/1000mpbs RJ45 ports to meet the gigabit network seamlessly.

Provide two 10/100/1000mpbs SFP fiber module slot ports and use the SFP fiber module.It is convenient to connect to the fiber backbone network.MDI/MDIX automatic flip and self-negotiation are supported on each port.Support IEEE 802.3x full duplex current control and Backpressure half duplex flow control.

Intelligent power management 1 ~ 24 port has PoE recognition. If the power of electrical equipment exceeds IEEE 802.3af standard, the system automatically starts IEEE 802.3at standard and priority mechanism port power supply.According to the IEEE802.3af/at standard, automatic detection and identification of PD equipment conforming to the IEEE802.3af/at standard and power supply for it, single port power can reach 30W.

Technical Specifications:

• PoE port 1-24 support IEEE802.3af/at

• SFP port support

• PoE port output power 15.4W/30W IEEE802.3af/at

• PoE wire core 1/2+?3/6- Lines(or 4/5+?7/8- Lines)

• PoE total power =400W

• PoE connection standard IEEE 802.3af/IEEE 802.3at

• PoE type End span

• POE power transmission distance =200m

• Web standards IEEE 802.3? IEEE802.3u?802.3x?802.3af/at

• Network media 10/100/1000mpbs.5 classes and above non-shielded double stranded wires

• Network signal distance transmission=100m

• backplane bandwidth 8.8Gbps backplane bandwidth

• Way forward Storage of forwarding

• Forward rate 10BASE-T:14880PPS/port 100BASE-tx:14800pps/port 1001000BASE-T: 1488095pps/port

• MAC address 16K's MAC address table

• Port functions Power priority mechanism, fast and forwarding, MAC automatic learning and aging IEEE802.3X full duplex current control and Backpressure half duplex flow control

• Indicator light Each port has one LINK/ACT. 100/1000mbps

• Indicator light POE Status indicator SFP indicator light, whole machine power indicator light

• work environmentWorking temperature:-10°-- 55°C

• input power AC110-240V 50/60HZ

• Machine Power Maximum 400W (power supply)

• weight 4.2kg

• size 440mm*284mm*44mm(L*W*H)
