Name: Komutatorius (Switch) Dahua DH-PFS4228-24T
Brand: Dahua
Price: 198 EUR
Availability: OutOfStock

Prekės informacija

Bendrosios charakteristikos

Prekės tipas

Komutatoriai (Switch)

Prekės ženklas

Dahua

Modelis

DH-PFS4228-24T

Šakotuvo tipas

Managed

Gylis

263 mm

Plotis

442 mm

Tinklo standartai

IEEE 802.1Q

Tinklo (LAN) jungčių greitis

1000 Base-X

Base T jungčių skaičius

Garantija

24 mėn

Prekės atspalvis gali skirtis nuo matomo nuotraukoje.

Prekės aprašymas anglų kalba:

PFS4228-24T

24-Port Ethernet Switch (Managed)

> 2-layer managed switch
> Provide web- based layer 2 network management by simple operation
> Support high-speed data forwarding, perfectly designing for large flow of video data forwarding in security surveillance
> Support one-key recovery of IP address & user password

Technical Speciﬁcation
Model	DH-PFS4228-24T
Ethernet Port	21000 Base-X (SFP) 210/100/1000 Base-T 24*10/100 Base-T
Switch Capacity	24.8G
Packet Forwarding Rate	9.52Gpps
Packet Buffer Memory	8Mb
MAC Table Size	16K
Exchange Mode	Store & forward
Application Humidity	0%-95%
Power	AC 100-240V
Power Consumption	≤30W
Lightning Protection	Common Mode 2KV Differential Mode 1KV
Working Temperature	﹣10°C-55°C
Weight	3.05kg
Dimension(W×D×H)	442mm×263mm×44.5mm

Accessories
Model
PFT3950	1.25G 850nm,500m,LC, Multi-mode
PFT3960	1.25G 1310/1550nm,20km,LC, Single-mode
PFT3970	1.25G 1550/1310nm,20km,LC, Single-mode

Service Characteristics
System	Username / password: admin/admin
System	IP Address :192.168.1.200/24
VLAN	Port-based VLAN
VLAN	802.1Q Standard VLAN
Spanning Tree	STP
Spanning Tree	RSTP
Port Aggregation	Link aggregation
Mirroring	Support many-to-one port mirroring
Flow Control	Support half-duplex based on back pressure type control
Flow Control	Support full duplex based on PAUSE frame
Multicast	IGMP Snooping
Security Features	Hardware supports IP+MAC binding based on port
Security Features	Support IEEE802.1x port authentication
System Maintenance	Support the configuration file upload/download
	Support the updated packet upload
	Support system logs
Network Management	WEB(http and https protocol)
