Product Information

Bus Interface	PCI-Express 3.0 x8
Number of Channel / Port	4x M.2 NVMe port (Dedicated PCIe 3.0 x4 per port)
Data Transfer Rate	8GT per lane / 8Gbps per lane
Number of device	4x M.2 NVMe SSD
SSD Form Factor	2242/2260/2280/22110 (supports single & double sided)
Form Factor	Full-Height
Card Dimensions	7.68" (W) x 4.38" (H) x 0.73" (D)
Card Weight	1.39 Ibs

Supported Operating Systems

Windows	Windows 10, Windows Server 2016 or later, Microsoft Hyper-V
Linux	Linux Kernel 3.10 or later
macOS	macOS 10.13 or later
System Requirements	Mac Platforms: • Apple Mac Pro Systems: 2012 and later Mac Pro systems; 5.1, 7.1 (2019) • Apple M1 Platform compatible • Thunderbolt™ 3 Connectivity via Thunderbolt™ Expansion chassis: RocketStor6661A
System Requirements	PC Platforms: • Any PC Systems or Motherboard with an industry standard PCIe x8 or x16 physical Slot (Bifurcation is not required) • Thunderbolt™ 3 Connectivity (requires a PC platform with a Thunderbolt 3 port) & Thunderbolt™ Expansion chassis: RocketStor6661A
Cooling System	Fan-less, Full-length anodized aluminum Heat sink
Fan Control	Yes (Windows, Mac)

NVMe Configurations

RAID Support	Single,RAID 0, 1, 1/0
TRIM RAID Support	Single,RAID 0, 1, 1/0
Data RAID(Non-Bootable)	Windows, Linux, Mac
BootRAID	Windows: Not supported Linux: Not supported Mac：Bootable using one (non-RAID) M.2 SSD as the boot drive. Only supports up to macOS 10.15.

NVMe RAID Management

Management Suites	Browser-Based management tool CLI (Command Line Interface- scriptable configuration tool) API package
SMTP Email Alert Notification	Yes
Alarm Buzzer	Yes
Storage Health Inspector	Yes
NVMe SMART status	Yes
Automatic and configurable RAID Rebuilding Priority	Yes
Auto resume incomplete rebuilding after power on or reboot system	Yes
Single-RAID or Multi-RAID Arrays per Controller	Yes
Cross-Sync RAID Solution Across Controllers	Yes

Operating Environment

Work Temp	+5°C ~ + 55°C
Storage Temp	-20°C ~ +80°C
Operating Voltage	PCI-e: 12V, 3.3V
Power	Typical: 7.65W
MTBF (Mean Time Before Failure)	920,585 Hours
Certification / Approval	CE, FCC, RoHS, REACH, WEEE
